Universal Quick release plate Sunwayfoto (DP-50R DP50R)

DP-50R universal quick-release plate is precision CNC machined from solid aircraft-grade aluminum, Arca-swiss compatible. Use for DSLR 135, 120 cameras, especially for bigger cameras with UNC3/8 mounting hole such as medium or large format cameras.

Features:

1. Precision machined from aircraft-grade aluminium with high quality surface anodizing.

2. It does not have convex edge, however it has got 2 soft rubber cushions on the surface. Meanwhile, this setting prevents the plate from shifting when it is used in vertical posistion.

3. The under side shows the Arca-swiss compatible dovetail with two safety stop mounting holes on the back of the plate.

4. Removable and adjustable backstop.

5. With a strap installing hole at one side to facilitate the attachment of a wrist strap.
6. Including parts: UNC1/4"-20 screw*1, UNC3/8"-16 screw*1, M3 safety stop screw*2, 4mm allen key*1, 2.5mm allen*1

Specifications:

• Length:50.7mm

• Width:42mm

• Thickness:9mm

• Weight:30.8g

• Mounting Hole:UNC1/4"-20 & UNC3/8"-16
