Genesis MH-20 Tilt Head

Genesis MH-20 is a "Tilt Head" designed for filming purposes and supplied with the Genesis MPC-3 monopod kit. MH-20 Head allows to tilt the camera backwards and forwards within the range of +/-90°. The precision of setting is ensured by a scale marked on the head.

The device is made of aluminium which makes it durable and lightweight at the same time. The entire framework weighs 330 g, while the maximum available load is 15 kg. Sleds are compatible with Arca-Swiss quick-releases which may be additionally protected against unwanted fall out by special bolts. Moreover, Genesis MH-20 has been equipped with a spirit level to increase the precision of setting. Solid knobs facilitate quick and seamless locking and unlocking of given head features. MH-20 Head features two replaceable hands. The shorter one is used during photo shoots, while the longer one transforms the head + monopod kit into a standard filming head (the entire monopod is rotated to achieve the rotational movement), and facilitates more comfortable and smooth frame adjustment.

The head may be also easily used with classic tripods with 3/8” mounting thread.

The Package Includes:

MH-20 Head
Quick-Release
Case
4 reduction items 1/4”-3/8” (3 screwed into the head)
Reduction Key
Allen Wrench

Specification:
Clamp Type:     Arca-swiss
Tilt Angle:     +/-90°
Width:     75 mm
Height:     90 mm
Mounting hole:     3/8"
Max. load:     15 kg
Weight:     330 g
